PRODUCT SUMMARY:
Increase your available parking capacity and protect your vehicles with the HAMMERHEAD 3.5T Four Post High Position Parking Lift Hoist—a practical, heavy-duty solution for making the most of your parking space!
The HAMMERHEAD 3.5T Four Post High Position Parking Lift Hoist is the ideal solution for maximising parking space in residential garages, apartment complexes, dealerships and vehicle storage facilities. Designed specifically for vehicle parking and storage, this high-position parking lift allows you to safely store one vehicle above another, making the most of your available floor space.
With a 3,500kg lifting capacity, 3.7m lifting height, and heavy-duty steel construction, this parking lift is built for dependable long-term performance. Diamond plate runways, a smooth hydraulic lifting system and an integrated drip tray system make it a practical and reliable choice for vehicle storage applications.
FEATURES
- 3,500kg (3.5 Tonne) lifting capacity
- Designed specifically for vehicle parking and storage
- High-position design provides up to 3.7m lifting height
- Maximises garage and parking space by storing one vehicle above another
- Heavy-duty steel construction for long service life
Durable diamond plate runways and approach ramps
- Manual mechanical safety lock release
- 240V single-phase hydraulic power unit
- Fast lifting time of approximately 50 seconds
- Four plastic drip trays and one steel oil collection tray included
- Powder-coated finish for corrosion resistance
- Low maintenance hydraulic lifting system
SPECIFICATIONS
|
Specification |
Details |
|
Lifting Capacity |
3,500kg |
|
Lifting Height |
3,700mm |
|
Overall Height |
4,116mm |
|
Overall Length |
5,778mm |
|
Overall Width |
3,050mm |
|
Runway Length |
4,780mm |
|
Runway Width |
483mm |
|
Lifting Time |
Approx. 50 seconds |
|
Motor |
240V Single Phase, 50Hz |
|
Lock Release |
Manual Mechanical |
INCLUDED
- HAMMERHEAD 3.5T Four Post High Position Parking Lift Hoist
- Hydraulic power unit
- Four plastic drip trays
- One steel oil collection tray
- Diamond plate runways and loading ramps
- Installation hardware
- Instruction manual
IMPORTANT NOTE
This hoist is designed for vehicle parking and storage applications. It is not intended for vehicle servicing or maintenance.
Warranty & Certifications
- 3 Year Australian Warranty – Includes Structure, Hydraulic & Electrics
- CE Certified
