PRODUCT SUMMARY:

Hammerhead Hoists is Australia’s Fastest Growing Hoist Range! Designed for professional garages, commercial service centres, and high-capacity home workshops, the Hammerhead 4.5 Ton 4 Post Repair Hoist is built for dependable performance across all general service and maintenance tasks.

The Hammerhead 4.5 Ton 4 Post Repair Hoist is a robust and versatile vehicle lifting solution, perfect for underbody work, mechanical repairs, fluid changes, and inspections. With a lifting capacity of 4,500 kg (4.5 tons / 9,900 lbs), it’s well suited for a wide range of vehicles, including sedans, utes, SUVs, 4WDs, and light commercial vehicles.

This four-post design provides exceptional stability, wide drive-on ramps for easy positioning, and a spacious working area beneath the vehicle—ideal for lifting heavy vehicles for extended periods. The open-centre layout allows for free movement of transmission jacks, tool trolleys, and workshop equipment underneath.

Engineered for durability, safety, and ease of use, the Hammerhead 4.5 Ton 4 Post Hoist is an essential addition to any serious workshop focused on vehicle repair, servicing, and maintenance.

• FEATURES
  • 4500KG / 4.5 Tonne Load Limit
  • Powder Coated Finish
  • Adjustable lifting height with maximum height of 1.7m
  • One side release for safety locks, easy for descent operation
  • External Locking

Safety Features

• 4-point pneumatic safety lock releases
• Additional secondary safety lock when weight comes off the cables
• Runways must first be raised a fraction before the safety locks will operate to allow the car hoist to be lowered
• Heavy duty 6mm thick cross beams and 5mm thick runways
• 9.53mm steel wire rope equalising cables
• Anti-surge valve

What’s Included?

• 4 post hoist with all bolts, cables, lines and fixings
• 415V Three Phase hydraulic power unit
• Oil Drip Trays

What’s Not Included?

• Power Plug
• Installation of unit
• Hydraulic Oil

Shed Requirements

• 150mm deep concrete
• Minimum Ceiling Height – 4 Metres

Warranty & Certifications

• Australian Worksafe Registered Design
• 3 Year Australian Warranty – Includes Structure, Hydraulic & Electrics
• CE Certified
